Index of Indian Railways Signal Engineering Manual (IRSEM)

Sl. Page
No. Contents No.

243. Chapter 22: Requirements of Signalling in 25 KV AC 474
Electrified Area

244. Section 1: General 474

245. Section 2: Signal Structures in RE area 475

246. Section 3: Erection of Signals in RE area 477

247. Section 4: Signalling Circuits in RE area 479

248. Section 5: Outdoor Signalling Circuits in RE area 480

249. Section 6: Signal feed Circuitry in RE area 480

250. Section 7: Point Operation & Detection in RE area 481

251. Section 8: Rules for Protection of Staff working on Signal & 483
Telecommunication Installation

Annexure 22-A1: Visibility of Signals in RE Area (Extracts of Para 20.5 of 487
252.
Appendix-1: Manual of AC Traction) Vol. II (Part-II)

253. Annexure 22-A2: Maintenance in Electrified Areas (Extract of part 'J' of 489
Permanent Way Manual PART 'J')

254. Annexure 22-A3: Clearances for Signals for High Rise OHE (For Running 494
Double Stack Container &Three Tier Car)

255. General Annexures 496

256. Annexure G1: Reliability, Availability, Maintainability & Safety (RAMS) 497

257. Annexure G2: Brief of High Speed Rail Signalling in Ahmedabad - 501
Mumbai Route

258. Annexure G3: Communication Based Train Control (CBTC) In Metro 508
Railway Systems

259. Annexure G4: Glossary of Technical Terms for Signal Engineering 514
Manual

Note: Maintenance Schedules are given in Appendix I.
Drawings are given in Appendix II.
