Index of Indian Railways Signal Engineering Manual (IRSEM)

Sl. Page
No. Contents No.

120. Chapter 11: Dataloggers & Predictive Maintenance Systems 220

121. Section 1: Dataloggers 220

122. Section 2: Applications of Datalogger 222

123. Section 3: Remote Diagnostic and Predictive Maintenance System 222

124. Annexure 11-A1: Datalogger Fault Logics - An Example 225

125. Chapter 12: Installation, Testing & Maintenance of Mechanical 236
Signalling Equipment

126. Section 1: Installation 236

127. Section 2: Point Rodding and Fittings 238

128. Section 3: Point Operation in Mechanical Signalling 239

129. Section 4: Facing Point locks, Switch & Lock Movements and Spring 239
Point Levers

130. Section 5: Location of Signals in Mechanical Signalling 240

131. Section 6: Signal Wire Run 245

132. Section 7: Painting of Mechanical Signalling 245

133. Section 8: Maintenance of Mechanical Signalling 247

134. Section 9: Maintenance of Lever Frame 248

135. Section 10: Maintenance of Lead outs (Rodding) 249

136. Section 11: Maintenance of point Rodding and Fittings 249

137. Section 12: Maintenance of Cranks, Compensators, Screws, Bolts, 250
Nuts, Pins and Cotters

138. Section 13: Maintenance of Points 250

139. Section 14: Maintenance of Facing Point Locks, Switch & Lock 251
Movements and Spring Point Levers

140. Section 15: Maintenance of Lock bars 252

141. Section 16: Maintenance of Mechanical Detectors 253

142. Section 17: Maintenance of Signal Wire Run (Single Wire) 254

143. Section 18: Maintenance of Pulley Stakes and Pulleys 254

144. Section 19: Maintenance of Electrical Repeaters and Signal Lamps/LEDs 254
