Para no. 9.3.1(b)                                                                          Annexure: 9-A3

 Station Machinery


 FORM VIII
 [See rule 5(1)(h)]
 STATION MACHINERY


                                                       Railway
 SECTION: LAKSHMIKANTPUR-KULPI                                                GAUGE: 1.676 M

 LENGTH: 9.19 km

 INTERLOCKING   SIGNALS
                                       Type of Block    Weigh Bridge
 Names of Station   Non-  Warners/   Advance
 Interlocked   Isolated   Outers   Home  Starters   working in use   No. & Capacity
 Interlocked   Distant      Starter

 1   2   3   4   5   6   7   8   9          10                11
                                     Single line Block
 LAKSHMIKAKTPUR   Yes   -   -   Yes   -   Yes   Yes   Yes    Nil
                                        Instrument
                                           Halt
 UDAYRAMPUR   No   Yes   -   -   -   -   -   -               Nil
                                      One Train only
 KULPI   No   Yes   -   -   -   -   -   -   Working System   Nil


 Note: The particulars furnished in this form are Illustrative.









 Chapter 9: Procedure for Commissioning of Signalling Installations   Page 197 of 535
