Para no. 9.3.1(b) Annexure: 9-A3

Station Machinery

FORM VIII
[See rule 5(1)(h)]
STATION MACHINERY

Railway
SECTION: LAKSHMIKANTPUR-KULPI GAUGE: 1.676 M

LENGTH: 9.19 km

INTERLOCKING SIGNALS
Type of Block Weigh Bridge
Names of Station Non- Warners/ Advance
Interlocked Isolated Outers Home Starters working in use No. & Capacity
Interlocked Distant Starter

1 2 3 4 5 6 7 8 9 10 11
Single line Block
LAKSHMIKAKTPUR Yes - - Yes - Yes Yes Yes Nil
Instrument
Halt
UDAYRAMPUR No Yes - - - - - - Nil
One Train only
KULPI No Yes - - - - - - Working System Nil

Note: The particulars furnished in this form are Illustrative.
