S.No. Description Yes/No/NA
j) Implantation Register of all signals jointly recorded with SSE/P/Way.
4 Pre-commissioning Check Lists for Equipments:
a) Electronic Interlocking.
b) DataLogger.
c) Integrated Power supply System.
d) SSDAC/HASSDAC/MSDAC.
e) UFSBI and Block Panel.
f) LED Signal units.
Ensure that all items are complied with appropriate remarks and signed
on all pages by concerned supervisors and OEMs representative,
verified by field ADSTE/DSTE and countersigned by Dy.CSTE/Sr.DSTE).
5 Installation & Maintenance Manuals for
a) Electronic Interlocking.
b) DataLogger.
c) Integrated Power Supply system (IPS), Solar Panels (if any).
d) SSDAC/HASSDAC/MSDAC.
e) UFSBI and Block panel.
f) Earth Leakage Detector (ELD).
6 Maintenance Registers for
a) Signaling Assets History Book.
b) Point Machines.
c) Track Circuits.
d) Axle Counters.
e) Signals.
f) IPS.
g) Batteries including Initial Charging.
h) Earth Resistance.
i) Joint Point & Crossing Inspection Register for newly laid points.
j) Signal Failure Register
7 Painting & Labeling:
a) Description writing of CT rack, Relays, Power supply distribution
board, IPS, Batteries, Location boxes etc.
