P. 51
Para No. 3.3.1 (d) Annexure: 3-A1
Form No.S&T./SC 3.3.1
Signal Visibility Certificate for Existing Signals
………………….RAILWAY
SIGNAL & TELECOMMUNICATION DEPARTMENT
Name of the station: …………………….., Section: ………………………..………. Division: ..………………………………... Signalling Plan No: ………………………
Note: Minimum visibility in MACLS territory: Distant signal: 400 meters, Inner Distant/Stop signal: 200 meters.
We, the undersigned members of the Signal Sighting Committee having met at ……………………….…….. and sighted the visibility of the Signals noted,
below, made following observations along with action proposed to be taken.
Signal No & Description History of Complaints /SPAD at this signal Obstruction by Tree Branches Interference from Fixed Lights Height of the normal aspect of the Signal above rail level Implantation in meters of the Signal from the adjacent Left side track implantation in meters of the Signal f
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) (12) (13) (14) (15)
Signature …………………….. Signature …………………….. Signature ……………………..
Name & Designation ………………….. Name & Designation ………………….. Name & Designation …………………..
Date ………………………….. Date ………………………….. Date …………………………..
Chapter 3: Duties Of Signal Supervisors And Technical Staff Page 29 of 535
