(v) Abnormal disappearing of train describer tag shall generate an alarm
and display in different colour.

(d) Control Function:

After taking control of an area, the central controller will be able to send
commands to the corresponding interlocking. The possible commands are:

(i) Setting/cancellation of route.

(ii) Moving point to Normal or Reverse.

(iii) Controlling signal (ON/OFF) as permitted by interlocking.

(iv) Setting/cancellation of traffic & power block.

(v) Turning the ARS mode ON/OFF, long route setting & route stacking.

(vi) Loading of Timetable/Train Chart.

(e) Automatic Route Setting (ARS):

(i) The automatic route setting feature will be possible to be provided for
identified stations/routes/sections.

(ii) The ARS system relieves the operator from repetitive route setting tasks
for the trains at these stations and the operator can monitor the train
operation from OCC (Operation Control Centre). The system shall
execute the commands according to timetable.

(f) Long Route Setting & Route Stacking: The chief controller/section
controller in OCC can set long route for one station to another station.
Provision of Route stacking shall be made to set routes of multiple trains in
advance.

(g) Block Working Operation:

(i) Block Operation for EI station will be done through CTC controller from
OCC. Suitable failsafe provision of inbuilt block operation system in EI is
needed for this and Conventional block instrument/panel may not be
used for block operation. In case inbuilt block working in EI is not
available, local operation of block instrument will be done by SM at
station.

(ii) For PI/RRI stations operation of block instruments/block panel may be
required to be done by SM at station.

Chapter 13: ATP, ETCS, IRATP (TCAS) & TMS Page 290 of 535
