Note : This Chapter has under mentioned Annexures

S.No Annexure No Description

1 22-A1 Visibility of Signals in RE Area (Extracts of Para 20.5 of
Appendix-1: Manual of AC Traction)
2 22-A2 Maintenance in Electrified areas (Extract of part 'J' of
Permanent Way Manual)
3 22-A3 Clearances for Signals for High Rise OHE (for Running
Double Stack Container & Three Tier Car) Vol. II (Part-II)

This Chapter has under mentioned Drawingsin Appendix II
S. No Drawing No Description

1 22-D1 Signal Clearance Diagram to Suit 25 KV AC Traction for Tangent
Tracks and Curved Tracks with S.E.60.
2 22-D2 Signal Clearance Diagram to Suit 25 KV AC Traction for Curved
Tracks with 60 to 140 S.E.
3 22-D3 Signal Clearance Diagram to Suit 25 KV AC Traction for Curved
Tracks with 140 to 185 S.E.
4 22-D4 Colour Light Signal Left Hand or Right Hand Broad Guage
(Tangent Track).
5 22-D5 Colour Light Signal with Junction Route Indicator Left Hand or
Right Hand Broad Gauge (Tangent Track).
6 22-D6 Distance in Rear from the Signal in Meters
7 22-D7 Distance in Rear from the Signal in Meters for High Rise OHE

8 22-D8 Implantation of OHE Structures with respect to Colour Light
Signal.
9 22-D9 Signalling Feed Arrangement with Cut-In Relays.

Chapter 22: Requirements Of Signalling in 25 KV AC Electrified Area Page 486 of 535
